Audion D545 AH

Continuous Horizontal Band Sealer

The Audion D545 AH is a continuous horizontal band sealer for pouches sealed in a horizontal position. The D545 has the advantage of a compact modern design and is ideal for applications that require the accurate control of sealing temperature for consistent seal integrity.

This smart tabletop model uses pre-made bags that are sealed lying flat. The flexible D545 AH band sealer uses PTFE belts to seal polyethylene, polypropylene, and other foil laminated pouches and bags. The maximum distance between the seal and the top of the bag is 1.9 inches. This band sealer has a temperature controller with a digital readout and includes an automatic cool down function. The integrated conveyor belt is adjustable in height to accommodate thin to thick packages and can be pulled out to 2.75” towards the operator to accommodate larger products. The packages move from right to left.

The industrial Audion D545 AH Horizontal Band Sealer is made in Germany and includes a 3-year limited warranty.

Videos

Specifications

ModelD 545 AH Band Sealer
Seal Width3/8”
Max Seal Tempup to 480° F (250° C)
Conveyor Belt Size4.4” W x 26.4” L
Max Seal SpeedAdjustable up to 400”/min
(up to 10 meters/min)
Cooling Bar Length4.25"
Electrical Requirement115V
Dimensions (WxDxH)27” x 18-22” x 10”
Weight67 lbs
Warranty3 year limited
Country of manufactureGermany

Features

Set-Up Benefits

  • Accurately set seal temperature with digital temperature controller
  • Manually adjustable seal pressure for packaging versatility
  • Seal speed up to 400 inches/min
  • Compact machine size to fit on a table

Safety Benefits

  • Emergency stop button
  • CE compliant design

Operating Benefits

  • Adjustable bag guide
  • Requires minimal maintenance
  • Adjustable conveyor can be pulled out up to 2.75” for larger packages

User Benefits

  • Flexible pouch sealing with variable seal temperature up to 480°
  • Integrated conveyor
  • Automatic cool down cycle

Safety Benefits

  • Emergency stop button
  • CE compliant design
