Coffee Pac Express

Products > Nozzle Vacuum Sealers > Vacuum Sealers for Coffee > Coffee Pac Express

Vacuum Sealer Perfect for High Volume Roasters

This high production floor model vacuum sealer is larger than our standard Coffee Pac. The Coffee PAC Express is a vacuum/nitrogen flush (or other inert gas flush) sealer designed for the most demanding roaster. It provides high volume roasters with the ability to vacuum pack up to six 1 – 2 lb. or three 5 lb. bags of whole bean or ground coffee at once. This vacuum sealer features an open head design for easier bag handling.

The Cofee Pac Express uses a 3/4 HP electric vacuum pump with vacuum reserve tank for faster air evacuation.
This vacuum sealer features a particle ejection system to clear the vacuum lines of any coffee debris after every vacuum cycle.
The Coffee Pac Express can flush the bag with nitrogen or any other desired gas.
The flushing sequence can easily be changed from vacuum then gas, to gas then vacuum, or gas only with no vacuum.

PVK Coffee Pac Express - 12oz Coffee Bag Run-Off (Nitrogen Flushing)

Features

Sealing

Seal Length: 36″
Seal Width: 5/16″
Bi-Active Seal: Top and bottom heated seal bars for thick materials or reducing seal time
Open-head design provides easy access to bag positioning
Pneumatically-operated seal jaws for high-pressure sealing
Pressure-evening system for sealing thick or gusseted bags
Thermal impulse time control system
Independent timers for vacuum, seal, and cool (up to 15s vacuum, 3.75s gas, seal, and cool)
Foot pedal cycle activation

Vacuum System

3/4 HP electric vacuum pump
Vacuum reserve tank for faster evacuation
Six high flow, stainless steel nozzles
Gas flush after vacuum, if required
Particle ejection system automatically clears debris or product from the nozzle after each cycle

Versatility

Individual controls allow vacuum only, gas flush only, or gas flush after vacuum
Designed to package whole bean or ground coffee in flat or gusseted bags
Seals a wide variety of poly or foil materials

Safety

Low-pressure jaw closing system
Automatic jaw interference release

Options

Vacuum Options

Bag Cassette: Allows bags to be shaped into brick-like packs during the vacuum cycle process
Multi-Stage: Perform up to two vacuum and gas cycles to achieve a lower residual oxygen level
Vacuum Level Sensor: Ensures consistent vacuum levels are achieved every cycle
Vacuum Relief Valve: Sets a maximum vacuum level to prevent product damage

Seal Options

Suretemp™ Temperature Controller: Ensures consistent seal quality (up to 350°F)
Seal Jaw Selector Switch: Allows bottom seal jaw to be turned off
Seal Only Switch: Retracts nozzles for use as a bag sealer (no vacuum)

Safety Options

Emergency Stop Button
Two Stage Cycle Engagement: Jaws close by foot pedal, cycle initiated by dual palm buttons
Locking Control Box Cover: Cover on control cabinet to prevent unauthorized setting changes
Dual Palm Buttons: Prevent operator contact with seal jaws during closure
Motorized Crank Adjustable Frame: Adjust the operating height of the machine for improved ergonomics

Other Options

Hot Embosser: Up to 8 brass characters 3/8″ above the seal
Hot Stamp Printer: Hot embosser with thermal transfer ribbon
SureSeal Digital Interface: Includes 9 program job storage, cycle counter, and multiple vacuum/gas cycles
NEMA Enclosure: Isolate electrical and pneumatic components from environmental conditions
Stainless Steel Construction: For wet or corrosive environments
Integrated Air Compressor
CE Compliant
Casters
